Edan Acclarix AX9 Portable Ultrasound

The Edan Acclarix AX9 is a portable ultrasound system designed for cardiac diagnostics and emergency applications. It features the SynSight Platform with Zone sonography technology, which acquires and processes ultrasound data more efficiently by covering the field of view in fewer transmit/receive cycles. The system retrospectively reprocesses raw echo information in the channel domain processor to form optimal images.

The AX9 includes a comprehensive suite of automated analysis tools for rapid clinical assessment, including left ventricular function evaluation, cardiac output measurement, fluid responsiveness assessment, and vessel analysis for vascular access and stroke risk evaluation. Smart Workflow automation enables quick protocols suitable for emergency departments and point-of-care settings.

• Auto eLV package with automatic EF, strain, and wall motion abnormality scoring
• Auto EF (M-mode) for automatic diastole/systole recognition
• Auto IVC for collapsibility and distensibility index measurement and fluid response assessment
• Auto CO with automatic LVOT diameter and VTI measurement for cardiac function assessment
• Auto B-Line for rapid lung ultrasound evaluation
• eWorks protocols including eFAST for emergency applications
• eDiam for automatic vessel diameter and distensibility assessment (fistula maturity)
• eSten% for automatic vessel stenosis percentage calculation (stroke risk assessment)
• Live VF with one-click vascular fistula parameter acquisition
• SynSight Platform with Zone sonography technology for optimized image acquisition
